Pièces spéciales en Titane

H240 flange with 3 Ervac E 9 points normal density 1 Ervac A 15 points normal density and 2 Ervac D 29 DVI

H10 peek flange with a threaded rod

H300 flange with 5 Modules F 4SMA

  H265 flange with 1 high density 2*15 point F Module and 1 2*RJ45 6A F Module

  H300 flange with 4 F Modules 2*09 points normal density and 4 Modules F 25 points normal density

  Flange H300 with 6 F 3W3 Power Modules

  H300 Flange with 4 Normal Density F 2*09 Point Modules and 1 High Density F 2*15 Point Module

VF150 flange with 3 Ervac D 78 points high density and 2 Ervac B 25 points normal density

VF 150 flange with 3 Ervac D 78 points high density and 1 Ervac B 25 points normal density

Special flange according to customer dimensions DN350.
10 * ERVAC D 50 M/F I ND

DN100 ISO-K flange.
1 ERVAC D 78 DSub High density
1 insert for LEMO Connectors.

Feedthrough for pressure application 100 bars.
Wired feedthrough.
Specific mechanical design for pressure.

M30 Nut & Bolt design in Plastic (PE) with Brass M10 thread roll.
Power application.

Customer design GALILEO wired flange with 50 type K thermocouples. Individual identification with heat-shrink sleeves.  Overall nylon protective braid on atmo side

Special Wired Thread feedthrough M50 with 5 x AWG10, multi-strand, PTFE.
